Relay Description
K17 Auxiliary relay, +15
K18 Waist working lights, front
K19 Auxiliary relay, +15
K20 Rear working lights
K21 Direction indicator
K22 Intermittent control relay, front
4.8.6.7 Fuses and relays for the urea component
The fuse diagram is placed inside the fuse box. There is space for spare fuses.
GUID-FEF087D8-8D9F-416B-8C1F-DBEC2B27E05C
Fuse
Nominal current Description
F1M 30 A DEF system heaters
F2M 30 A EEM supply
F3M 2 A EEM wake up
GUID-06006F26-80B8-419F-9688-BC0AFB991437
