Fuse Nominal current Description
F25 10A TC1 (VP3), F/N/R/P-lever
F26 10A Transmission sensors
F27 5A 3-pole current socket, VMT
F28 5A Cruise switches
F29 10A Reserve
F30 5A Instrumentation
F31 10A Transmission sensors
F32 10A Parking ensure
F33 10A Twin-Trac, front PTO, front and
cabin suspension
F34 15A Radio, electrical mirrors,
handsfree, rear wiper/washer
F35 15A Seat, rear steering prevent
F36 25A Fan
F37 30A Reserve
F38 25A Light switch
F39 25A 3-pole current socket
F40 25A TC1 (VP1+VP2+VP3)
F41 15A Rear working lights, left
F42 15A Rear working lights, right
F43 15A Waist working lights, front
F44 15A Waist working lights, front
F45 30A Waist working lights, rear/roof
F46 10A Parking lights, left
F47 10A Parking lights, right
F48 10A Parking lights, illum., 2–pole
current socket on the bonnet
F49 15A Front working lights
Relay Description
K1 Brake lights
K2 Parking ensure
K3 Air condition
K4 Reserve
K5 Reserve
K6 Fuel pump, CR/VE engine
K7 Reserve
K8 Reserve
K9 Low beam, hood
K10 Main switch
K11 Reserve
K12 Waist working lights, rear
K13 Hand brake input
K14 Auxiliary relay, +15
K15 Parking lights
K16 Front working lights
Table continued on next page
4. Maintenance
- 315 -
