• In the basic mode view, the tractor symbol and the current driving speed are
shown if the tractor is moving. In the fixed view, they are shown continuously.
The accuracy of the driving speed view is described in the following table.
Driving speed Accuracy
0.0-9.9 0.1
10.0-14.8 0.2
15 and above 1 (no decimals)
• The clock symbol is shown when the clock mode has been selected. The
time is shown on the bottom line.
• When the SCR (Selective Catalytic Reduction) mode has been selected the
Low AdBlue level symbol, letter L and the level of the AdBlue/DEF (in
percent) is shown continuously.
This view is shown every time when the power has been turned on if the level
of the AdBlue/DEF is between 10-15%. The view can be changed with the
view selection switch.
When the level of the AdBlue/DEF is below 10%, the letter L and the level of
the AdBlue/DEF (in percent) is shown continuously. The view can not be
changed with the view selection switch.
When the level of the AdBlue/DEF is below 5%, the Low AdBlue level symbol
flashes.
• In some situations (for example, after working with a heavy load) when you
engage the parking brake, the engine may perform cooling of the after-
treatment system by increasing the idling RPM momentarily. The word COOL
flashes on the A-pillar display.
IMPORTANT: Do not stop the engine when the idling RPM is increased.
Stopping the engine may damage the after-treatment system.
• The service code symbol blinks if one or more service codes are active. The
symbol disappears when the error has been fixed and power turned off.
3.11.4 Changing general information section views
You can change the general information section view by pressing the view
selection switch.
GUID-38149417-A00B-43B9-A575-2AB0813CC183
1. View selection switch
3. Operation
- 155 -
