Valtra HiTech T3 Series User Manual

3.20.5 Euro pick-up hitch with hydraulic extension
The Euro pick-up hitch with the hydraulic extension is otherwise similar to the
Euro pick-up hitch, but you can move it hydraulically in longitudinal direction.
3.20.5.1 Unlatching the hydraulically extended Euro pick-up hitch
3
6
4 5
2
1
AUT
O
A
U
T
O
M
I
N
M
A
X
P
GUID-3951B793-8011-47F1-8F6A-E74887EC0912
1. Lifting height selector
2. Draft control selector
3. Pick-up hitch latch releasing switch
4. Lift/stop/lower switch
5. Passing switch for the position control knob
6. Position control knob
1. Set the lifting height selector to max position.
2. Set the draft control selector to position P.
3. Set the position control knob to position 8.
4. Press down the side opposite to the symbol of the lift/stop/lower switch.
5. Press down simultaneously the passing switch for the position control knob
and the pick-up hitch latch releasing switch.
The pick-up hitch latch unlatches.
3. Operation
- 223 -
