1. Select a view by pressing the view selection switch.
The views are organised in the following order: basic mode, rear power take-
off speed, front power take-off speed (if the tractor is equipped with the front
power take-off), outdoor temperature, driving speed, time, AdBlue level.
• To scroll through the functions in this order, press down the symbol side
of the switch.
• To scroll through the functions in reverse order, press down the side of
the switch opposite to the symbol.
The basic mode shows the outdoor temperature when the tractor does not
move. When the driving speed is greater than 0.3 km/h, the speed is shown
instead of the temperature.
When both the rear power take-off and front power-take off are in use the
rear power take-off speed is shown on the A-pillar display.
2. The last used display mode is saved when turning off the power.
3.12 Rear linkage
1
2
3
4 5
8
7
6
10 11
9
A
U
T
O
A
U
T
O
M
IN
M
A
X
P
GUID-95723F5F-E5EC-4601-888C-CF68B0127F73
1. Diagnose light
2. Lowering speed selector
3. Lifting height selector
4. Draft control selector
5. Drive balance control, including slip control system
6. Lift/lower indicator lights
7. Drive balance control light
8. Slip control light
9. Position control knob
10. Passing switch for position control knob
11. Lift/stop/lower switch
3. Operation
- 156 -
