Valtra HiTech T3 Series User Manual

2. Turn up the link.
1
GUID-5544ECF6-E0D3-494E-ABB3-4801D2E7C410
1. Link
3. Lift up the turning handle.
1
GUID-27DAF850-6E21-4D33-8448-AB0744D008C5
1. Turning handle
4. Adjust the length of the check link by turning the handle.
IMPORTANT: If you shorten the right lifting link, check that the side limiter
does not hit the tractor when the lifting link is raised to maximum height.
1
GUID-9FD97BA9-F391-4D73-A222-E5B0C4A5092F
1. Turning handle
5. After completing the adjustment, perform the steps in the reverse order.
6. Lock the check link adjustment with the closure pin.
3. Operation
- 176 -
