GUID-90B7436B-F0FA-487B-931D-B5F086BEEC95
1. Towing pin locking lever
2. Towing pin opening lever
1. Lift the towing pin up.
To lift the pin, turn the opening lever to the upper position.
2. Attach the trailer to the coupling.
When the draw eye reaches the bottom of the draw gap, the towing pin
automatically goes down. You can also lower the towing pin by pushing the
lowering lever downwards.
3. Check that the towing pin is locked.
GUID-BA8488DE-C3E5-4789-B584-23A51901F313
1. Towing pin not locked
2. Towing pin locked
WARNING: The drawbar pin is locked in the down position when
the security knob is out. When attaching the trailer, the drawbar
locking pin must be secured.
3. Operation
- 220 -
