GUID-BCAA2B28-5D82-4E97-B443-173E1C3B3B9C
1. Lift/lower switch
2. Pick-up hitch latch releasing switch
1. Reverse the tractor up to the pick-up.
2. Align the pick-up hitch hook or drawbar pin to the eye of trailer/implement beam.
3. Press the opposite side to the symbol of the lift/lower switch to raise the
linkage fully up until the hitch latches.
GUID-D83D9AD8-E90F-4B3E-B06B-B43359FD021B
1. Locking indicator
In locked position, the locking indicator is hidden into the grooves of the side
plates of the pick-up hitch.
You can hear a click when the hitch latches.
4. Press the symbol side of the lift/lower switch to lower the linkage slightly.
Ensure that the hitch is supported by the latch and does not lower with the
linkage.
3. Operation
- 226 -
