4. Pull the cable clearance to the end of the cable.
GUID-4D9BE4F6-2A03-486A-BC39-42E57D61D24D
1. Cable
2. Clearance
3. Adjusting nut
4. Locking nut
5. Open the locking nut.
6. Adjust the clearance through the adjusting nut so that it is 1-2 mm.
7. Tighten the locking nut.
IMPORTANT: When mounting the parking brake cable, the cylinder side end has
to be mounted according to the tolerances. This should only be carried out by an
authorised workshop.
4. Maintenance
- 270 -
