2. Remove the drain plugs under the gearbox and final drives.
GUID-6B0DFDCB-F4C4-4FE2-B52F-BFD7451DB03A
1. Final drives drain plugs
2. Gearbox drain plug
3. Drain the oil into a suitable container.
4. Clean and refit the plugs.
5. Clean the suction strainer.
6. Change the transmission oil filters.
7. Remove the top link to reach the filling plug located behind it.
8. Fill the oil through the filler cap.
GUID-DCF7AD26-5890-43D5-9249-626CE97DE49F
1. Transmission oil dipstick
2. Transmission oil filling plug
4. Maintenance
- 292 -
