1. Seat depth and cushion angle adjustment
2. Storage compartment for manuals
3. Headrest height adjustment and removal
4. Seat heating
5. Lumbar support adjustment
6. Seat turning lock/release
7. Armrest adjustment
8. Forward/backward adjustment
9. Backrest inclination adjustment
10. Longitudinal suspension adjustment
11. Height and vertical suspension adjustment
12. Suspension stiffness adjustment
13. Seat belt anchor point
• Adjust the seat depth and cushion angle.
• To adjust the seat depth, pull up the right handle in the seat front.
• To adjust the seat cushion angle, pull up the left handle in the seat front.
• Turn the seat.
• Release the lock by pulling the lock/release lever upwards.
• Turn the seat to the desired position.
The seat has set positions from 180° anti-clockwise to 30° clockwise at
intervals of 10°.
3. Operation
- 57 -
