GENERAL
M6040, M7040, WSM
G-89
NOTE
• Implement size may vary depending on soil operating conditions.
*1 Must remove front weight with this implement.
*2 Need subframe.
9Y1210143GEG0126US0
13 Front Loader
*1, *2
Max. Lifting
Capacity
1150 kg (2535 lbs)
Max. Oil Pressure 19.6 MPa (200 kgf/cm
2
, 2844 psi)
14 Box Blade
Max. Cutting Width 1820 mm (72 in.) 2130 mm (84 in.)
Max. Weight 450 kg (1000 lbs) 550 kg (1200 lbs)
15 Back Hoe
*2
Max. Digging Depth 2530 mm (100 in.)
Max. Weight 900 kg (2000 lbs)
16 Snow Blade
Max. Width 1820 mm (72 in.) 2130 mm (84 in.)
Max. Weight 450 kg (1000 lbs) 550 kg (1200 lbs)
No. Implement Remarks M6040 M7040
KiSC issued 07, 2012 A
