STEERING
M6040, M7040, WSM
7-S2
2. SERVICING SPECIFICATIONS
POWER STEERING CONTROLLER
POWER STEERING CYLINDER
9Y1210143STS0002US0
Item Factory Specification Allowable Limit
Relief Valve Setting Pressure At Idling Engine
Speed
At Maximum
Engine Speed
Above
12.3 MPa
125 kgf/cm
2
1777.9 psi
Below
18.1 MPa
185 kgf/cm
2
2631.3 psi
–
–
Item Factory Specification Allowable Limit
Steering Cylinder I.D. 55.000 to 55.074 mm
2.16535 to 2.16827 in.
55.100 mm
2.16929 in.
Rod to Bushing Clearance 0.010 to 0.140 mm
0.00039 to 0.00551 in.
0.250 mm
0.00984 in.
