CABIN
M6040, M7040, WSM
10-S33
[2] DISASSEMBLING AND ASSEMBLING
(1) Separating Cabin from Tractor
Drain Coolant
• Never remove the radiator cap until coolant temperature is
well below its boiling point. Then loosen cap slightly to the
stop to relieve any excess pressure before removing cap
completely.
1. Stop the engine and let cool down.
2. To drain the coolant, open the radiator drain plug (1). When
opening the drain plug set the hose to drain port.
3. Remove the radiator cap to completely drain the coolant.
4. After all coolant is drained, reinstall the radiator drain plug.
9Y1210143CAS0059US0
Coolant Capacity
8.0 L
8.5 U.S.qts
7.1 Imp.qts
(1) Drain Plug (2) Drain Plug
To Next Page
