GENERAL
M6040, M7040, WSM
G-39
[14] OTHERS
Bleeding Fuel System
Air must be removed:
1. When the fuel filter or lines are removed.
2. When water is drained from water separator.
3. When tank is completely empty.
4. After the tractor has not been used for a long period of time.
Bleeding procedure is as follows:
1. Fill the fuel tank with fuel, and open the fuel cock (1).
2. Pump the fuel pump knob (2) located on the top of the fuel filter.
The fuel pump knob will pump easily at first and with added
resistance as air is purged from the system. To make sure air is
completely purged, pinch the fuel overflow hose (3) with fingers,
if a pulsation is felt when the knob is pumped, then, no air
remains.
3. Set the hand throttle lever at the maximum speed position, turn
the key switch to start the engine, and then reset the throttle
lever at the mid speed (around 1500 min
-1
(rpm)) position.
If engine does not start, try it several times at 30 second
intervals.
4. Accelerate the engine to remove the small portion of air left in
the fuel system.
5. If air still remains and the engine stops, repeat the above steps.
• Do not hold key switch at engine start position for more
than 10 seconds continuously. If more engine cranking is
needed, try again after 30 seconds.
9Y1210143GEG0063US0
Bleeding Brake System
1. See page 5-S6.
9Y1210143GEG0064US0
Draining Clutch Housing Water
1. The tractor is equipped with drain plug (1) under the clutch
housing.
2. After operating in rain, snow or tractor has been washed, water
may get into the clutch housing.
3. Remove the drain plug (1) and drain the water, then install the
plug (1) again.
9Y1210143GEG0065US0
Replacing Fuse (ROPS Model)
1. See page 9-S11.
9Y1210143GEG0066US0
Replacing Fuse (CABIN Model)
1. See page 9-S12.
9Y1210143GEG0067US0
(1) Fuel Cock
(2) Fuel Pump Knob
(3) Fuel Overflow Hose
(A) Close
(B) Open
(C) Up
(D) Down
(1) Drain Plug (Water)
