wsm M7040 - 2 Servicing Specifications

CLUTCH
M6040, M7040, WSM
2-S2
2. SERVICING SPECIFICATIONS
TRAVELING CLUTCH
PTO CLUTCH
9Y1210143CLS0002US0
Item Factory Specification Allowable Limit
Clutch Pedal (ROPS Model) Free Travel
Tota l St r o k e
15 to 25 mm
0.59 to 0.98 in.
145 to 155 mm
5.71 to 6.10 in.
–
–
Clutch Pedal (CABIN Model) Free Travel
Tota l St r o k e
15 to 25 mm
0.59 to 0.98 in.
160 to 170 mm
6.30 to 6.69 in.
–
–
Item Factory Specification Allowable Limit
PTO Clutch Valve
Condition
• Engine Speed Maximum
• Oil temperature
45 to 55 °C (113 to 131 °F)
PTO Clutch
Operating
Pressure
2.16 to 2.26 MPa
22 to 23 kgf/cm
2
312.91 to 327.14 psi
–
PTO Clutch Disc Thickness 2.5 to 2.7 mm
0.098 to 0.106 in.
2.1 mm
0.083 in.
PTO Steel Plate Thickness 1.93 to 2.07 mm
0.076 to 0.081 in.
1.80 mm
0.071 in.
PTO Piston Flatness – 0.15 mm
0.006 in.
PTO Steel Plate Flatness – 0.30 mm
0.012 in.
PTO Return Spring Free Length 46.0 mm
1.811 in.
37.5 mm
1.48 in.
Seal Ring Thickness 2.45 to 2.50 mm
0.096 to 0.098 in.
2.0 mm
0.079 in.
KiSC issued 07, 2012 A
