FRONT AXLE
M6040, M7040, WSM
6-S4
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210143FAS0003US0
Item N·m kgf·m lbf·ft
Tie-rod end lock nut 167.7 to 196.1 17.1 to 20.0 123.7 to 144.7
Front axle rocking force adjusting lock nut 98.1 to 147.1 10.0 to 15.0 72.3 to 108.5
Power steering hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Front wheel mounting nut (M16) 259 to 304 26.5 to 31.0 191.7 to 224.2
Bracket mounting nut 123.6 to 147.1 12.6 to 15.0 91.1 to 108.5
Bracket mounting screw 166.7 to 196.1 17.0 to 20.0 123.0 to 144.7
Tie-rod end slotted nut 156.9 to 176.5 16.0 to 18.0 115.7 to 130.2
Tie-rod joint lock nut 166.7 to 196.1 17.0 to 20.0 123.0 to 144.7
Bevel gear case mounting screw (M16, 9T) 259.9 to 304.0 26.5 to 31.0 191.7 to 224.2
Front wheel case support mounting screw (M16, 9T) 259.9 to 304.0 26.5 to 31.0 191.7 to 224.2
Front wheel case cover mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Differential case cover mounting screw (USB) 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
