FRONT AXLE
M6040, M7040, WSM
6-S3
9Y1210143FAS0002US0
Front Bracket to Rear Bracket Bushing
• Rear Differential Case Boss
• Front Differential Case Boss
Alloy Thickness
O.D.
O.D.
0.57 mm
0.0224 in.
89.965 to 90.000 mm
3.5420 to 3.5433 in.
59.97 to 60.000 mm
2.3611 to 2.3622 in.
–
–
–
Front Wheel Case Support Bushing
• Bearing Retainer
Alloy Thickness
O.D.
0.57 mm
0.0224 in.
59.97 to 60.00 mm
2.36102 to 2.36220 in.
–
–
Front Wheel Case Bushing
• Bevel Gear Case
Alloy Thickness
O.D.
0.57 mm
0.0224 in.
54.97 to 55.00 mm
2.1642 to 2.1653 in.
–
–
Bevel Gear in Bevel Gear Case Backlash 0.20 to 0.30 mm
0.0079 to 0.0118 in.
0.4 mm
0.016 in.
Bevel Gear in Front Wheel Case Backlash 0.20 to 0.30 mm
0.0079 to 0.0118 in.
0.4 mm
0.016 in.
Item Factory Specification Allowable Limit
