ENGINE
M6040, M7040, WSM
1-S59
(10) Crankshaft and Crankcase
Crankshaft and Crankcase
1. Remove the crankcase 2 mounting screw and crankcase 2
flange screw in the order of Z to A.
2. Remove the crankcase 2 (1) from the crankcase 1 (2).
3. Remove the crankshaft (3).
(To be continued)
(1) Crankcase 2
(2) Crankcase 1
(3) Crankshaft
(a) Front Cover Side
(b) Flywheel Housing Side
A to J: Crankcase 2 Mounting Screw
K to Z: Crankcase 2 Flange Screw
To Next Page
