TRANSMISSION
M6040, M7040, WSM
3-S5
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210143TRS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 260 to 304 26.5 to 31.0 181.8 to 224.2
Shuttle valve pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Shuttle valve mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.2
Joint screw for hydraulic pipe 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Power steering hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Oil cooler pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Engine and clutch housing mounting screw and nut
(M14, 7T)
124.0 to 147.0 12.6 to 15.0 91.2 to 108.0
Engine and clutch housing stud bolt 61.8 to 73.0 6.3 to 7.5 45.6 to 54.2
Starter's B terminal mounting nut 9.8 to 11.8 1.0 to 1.2 7.2 to 8.7
Power steering pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Brake hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
ROPS under frame mounting frame screw (M16, 9T) 259.9 to 304.0 26.5 to 31.0 191.7 to 224.2
3-point hitch delivery pipe retaining nut 107.9 to 117.7 11.0 to 12.0 79.6 to 86.8
Transmission case and clutch housing mounting screw
and nut (M10, 9T)
60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Transmission case and clutch housing mounting screw
and nut (M14, 9T)
166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
Cylinder hose retaining nut 34.3 to 48.1 3.5 to 4.9 25.3 to 35.4
3-point hitch hydraulic block mounting screw and nut 166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
Rear axle mounting screw (M14, 9T) 166.7 to 196.1 17.0 to 20.0 123.0 to 144.3
Rear axle mounting nut (M14, 6T) 124 to 147 12.6 to 15.0 91.2 to 108
PTO gear case mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Damper disc mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Shuttle case mounting screw and nut 48.1 to 55.8 4.9 to 5.7 35.4 to 41.2
Shift cover mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Creep gear cover 48.1 to 55.8 4.9 to 5.7 35.4 to 41.2
PTO clutch holder mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
Differential bearing support mounting screw 48.1 to 55.8 4.9 to 5.7 35.4 to 41.2
Spiral bevel pinion shaft staking nut (Reference) 117.7 12.0 86.8
Spiral bevel gear mounting UBS screw 142.2 to 161.8 14.5 to 16.5 104.9 to 119.3
PTO shaft staking nut 225.5 to 264.8 23.0 to 27.0 166.4 to 195.2
