STEERING
M6040, M7040, WSM
7-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210143STS0003US0
Item N·m kgf·m lbf·ft
Power steering delivery hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Controller pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Oil cooler pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Power steering controller mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Power steering pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Power steering joint shaft mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
Brake hose retaining nut 22.6 to 27.5 2.7 to 2.8 16.6 to 20.3
Power steering delivery hose 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Tie-rod end slotted nut 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Hose joint 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Tie-rod joint 166.7 to 196.1 17.0 to 20.0 123.0 to 144.7
Gerotor assembly mounting screw (5/16') 25.5 to 28.4 2.6 to 2.9 18.8 to 21.0
