BRAKES
M6040, M7040, WSM
5-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210143BRS0003US0
Item N·m kgf·m lbf·ft
Brake rod turnbuckle lock nut 29.4 to 34.3 3.00 to 3.49 21.7 to 25.2
Bleeder 6.4 to 6.9 0.66 to 0.70 4.8 to 5.0
Brake pipe retaining nut 16.0 to 24.0 1.6 to 2.5 11.8 to 17.7
Master cylinder pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Plug 98.1 to 118 10.0 to 12.0 72.3 to 86.8
