wsm M7040 - 2 Servicing Specifications

CABIN
M6040, M7040, WSM
10-S5
2. SERVICING SPECIFICATIONS
9Y1210143CAS0002US0
Item Factory Specification Allowable Limit
A/C Compressor Magnetic Clutch Air Gap 0.30 to 0.65 mm
0.0118 to 0.0255 in.
–
Magnetic Clutch Stator Coil Resistance 3.0 to 4.0 Ω –
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
–
Pressure
(HI Pressure Side)
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Less than
approx. 0.196 MPa
2.0 kgf/cm
2
28.4 psi
–
Setting Pressure
(HI Pressure Side)
More than
approx. 3.14 MPa
32 kgf/cm
2
455 psi
–
Air-gap of A/C Compressor Magnet Clutch Air-gap 0.30 to 0.65 mm
0.118 to 0.255 in.
–
Air Conditioner Drive Belt Tension 11 to 12 mm
(0.44 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Front Wiper Rotating Speed 25 to 43 times/min –
Rear Wiper (Option) Rotating Speed 25 to 43 times/min –
KiSC issued 07, 2012 A
