CABIN
M6040, M7040, WSM
10-S6
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-13.)
9Y1210143CAS0003US0
Item N·m kgf·m lbf·ft
Power steering joint shaft mounting screw 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Brake hose nut 23.5 to 27.5 2.40 to 2.80 17.4 to 20.2
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.8 to 224.2
Brake hose retaining nut 16.0 to 24.0 1.6 to 2.4 11.8 to 17.7
Cabin mounting screw and nut 124 to 147 12.6 to 15.0 91.2 to 108
High pressure pipe 1 mounting screw (compressor
side)
7.9 to 11.8 0.8 to 1.2 5.8 to 8.7
Compressor mounting screw 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Magnetic clutch mounting screw 15.0 to 21.0 1.5 to 2.1 11.1 to 15.5
A/C unit mounting screw (M8) 9.8 to 15.7 1.0 to 1.6 7.2 to 11.6
Pressure pipe joint mounting screw (cooler unit side) 7.9 to 11.8 0.8 to 1.2 5.8 to 8.7
Low pressure pipe mounting screw (compressor side) 7.9 to 11.8 0.8 to 1.2 5.8 to 8.7
High pressure pipe 1 mounting screw (condenser side) 7.9 to 11.8 0.8 to 1.2 5.8 to 8.7
High pressure pipe 2 retaining nut (receiver side) 11.8 to 14.7 1.2 to 1.5 8.7 to 10.8
Wiper arm mounting nut (front wiper) 6.3 to 9.3 0.7 to 1.0 5.0 to 6.9
Wiper arm mounting nut (rear wiper) 7.9 to 9.3 0.8 to 1.0 5.8 to 6.9
Wiper motor mounting screw 7.9 to 9.3 0.8 to 1.0 5.8 to 6.9
