ENGINE
M6040, M7040, WSM
1-S12
• For "*" marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
9Y1210143ENS0003US0
Item N·m kgf·m lbf·ft
Idle gear mounting screw (10T) 30 to 35 3.0 to 3.5 22 to 25
Balancer shaft set screw 24 to 27 2.4 to 2.8 18 to 20
*Connecting rod screw 69 to 73 7.0 to 7.5 51 to 54
*Crankcase 2 mounting screw 138 to 147 14.0 to 15.0 101.3 to 108
Crankcase 2 flange screw 59 to 63 6.0 to 6.5 44 to 47
Oil pump cover screw 7.9 to 9.3 0.80 to 0.95 5.8 to 6.8
