CLUTCH
M6040, M7040, WSM
2-S11
Thickness of Seal Ring
1. Measure the thickness of seal rings (1) with an outside
micrometer.
2. If the measurement is less than the allowable limit, replace it.
9Y1210143CLS0018US0
[2] SOLENOID VALVE (PTO)
Solenoid Valve (PTO)
1. Refer to "[10] SOLENOID VALVE" on page 9-S47.
9Y1210143CLS0019US0
Thickness of seal ring
Factory specification
2.45 to 2.50 mm
0.096 to 0.098 in.
Allowable limit
2.0 mm
0.079 in.
(1) Seal Ring
(1) PTO Solenoid Valve
