HYDRAULIC SYSTEM
M6040, M7040, WSM
8-S3
POSITION AND DRAFT CONTROL LINKAGE
CONTROL VALVE
LIFT ARM AND TOP LINK BRACKET
9Y1210143HYS0002US0
Item Factory Specification Allowable Limit
Position Control Rod (ROPS) Length Approx.
159 mm
6.26 in.
–
Draft Control Rod (ROPS) Length Approx.
146 mm
5.75 in.
–
Position Control Rod (CABIN) Length Approx.
185 mm
7.28 in.
–
Draft Control Rod (CABIN) Length Approx.
182 mm
7.17 in.
–
Position Feedback Rod
(ROPS and CABIN)
Length 156 mm
6.14 in.
–
Draft Feedback Rod
(ROPS and CABIN)
Length 252 mm
9.92 in.
–
Position Control Floating Range 10 to 30 mm
0.39 to 1.18 in.
–
Uppermost Position of Lift Arm Cylinder Free Play 5 to 8 mm
0.197 to 0.315 in.
–
Draft Lever Free Range Floating Range Less than
25.0 mm
0.984 in.
–
Draft Floating Range Check Floating Range More than
15.0 mm
0.59 in.
–
Position and Draft Control Lever Operating Force 20 to 40 N
2.0 to 4.1 kgf
4.5 to 9.0 lbf
–
Item Factory Specification Allowable Limit
Spool Joint Length 24.5 to 25.0 mm
0.9646 to 0.9842 in.
–
Item Factory Specification Allowable Limit
Bushing Press-fit Location 11.0 mm
0.433 in.
–
KiSC issued 07, 2012 A
