ELECTRICAL SYSTEM
M6040, M7040, WSM
9-S2
LIGHTING SYSTEM
HORN
Symptom Probable Cause Solution
Reference
Page
Head Light Does Not
Light
Fuse blown Replace 9-S11
Bulb blown Replace G-40
Lighting switch defective Replace 9-S36
Illumination Light
Does Not Light
Fuse blown Replace 9-S11
Meter panel defective Replace 9-S25
Lighting switch defective Replace 9-S36
Tail Light Does Not
Light
Fuse blown Replace 9-S11
Lighting switch defective Replace 9-S36
Hazard Light Does
Not Light
Fuse blown Replace 9-S11
Bulb blown Replace G-40
Flasher unit defective Replace 9-S40
Hazard switch defective Replace 9-S39
Turn signal switch defective Replace 9-S36
Hazard and Turn
Signal Indicator
Lamp Does Not Light
Meter panel defective Replace 9-S25
Lighting switch defective Replace 9-S36
Hazard and Turn
Signal Light Does Not
Go ON and OFF
Flasher unit defective Replace 9-S40
Work Light Does Not
Light
Fuse blown Replace 9-S11
Bulb blown Replace G-40
Wiring harness disconnected or improperly
connected
Repair or replace –
Brake Light Does Not
Light
Fuse blown Replace 9-S11
Bulb blown Replace G-40
Symptom Probable Cause Solution
Reference
Page
Horn Does Not Sound
when Horn Button Is
Pushes
Horn switch defective Replace 9-S36
Horn defective Replace –
Wiring harness disconnected or improperly
connected (between combination switch terminal
H terminal and horn)
Repair or replace –
