GENERAL
M6040, M7040, WSM
G-30
Draining Fuel Tank Water
1. Loosen the drain plug (2) at the bottom of the fuel tank (1) to let
sediments, impurities and water out of the tank. Finally tighten
up the plug.
• If the fuel contains poor qualities with much water in it,
drain the fuel tank at shorter intervals.
• Drain the fuel tank before operating the tractor after a long
period of storage.
• The fuel tank is made of plastic. Be careful not to
overtighten the bolts.
9Y1210143GEG0030US0
Cleaning Inner Air Filter (CABIN Model)
1. Remove the knob bolt (2) and pull out the filter (1).
2. Blow air from the direction opposite to the filter's normal air flow.
Pressure of compressed air must be under 205 kPa
(2.1 kgf/cm
2
, 30 psi).
• Attach the filter as the illustration.
9Y1210143GEG0031US0
(1) Fuel Tank
(2) Drain Plug
[A] ROPS Model
[B] CABIN Model
(1) Inner Air Filter (2) Knob Bolt
