CABIN
M6040, M7040, WSM
10-S8
(Continued)
(Refrigerant)
(Compressor Oil)
*PAG: Polyalkyleneglycol (Synthetic oil)
(Reference)
*PAG: Polyalkyleneglycol (Synthetic oil)
9Y1210143CAS0004US0
Kinds of refrigerant
(Charge amount)
Factory specification
R134a
0.85 to 0.95 kg
1.87 to 2.09 lbs
Quantity (Total) Brand Name
100 to 120 cc
0.106 to 0.127 U.S.qts
0.088 to 0.106 Imp.qts
ND-OIL 8
<PAG* oil>
Replacing Parts Replenish Quantity Brand Name
Condenser
40 cc
0.042 U.S.qts
0.035 Imp.qts
ND-OIL 8
<PAG* oil>
Evaporator
40 cc
0.042 U.S.qts
0.035 Imp.qts
Receiver
10 cc
0.011 U.S.qts
0.009 Imp.qts
Hose
10 cc
0.011 U.S.qts
0.009 Imp.qts
KiSC issued 07, 2012 A
