Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-47
Troubleshooting
Registration Sensor
1. Enter Service Diagnostics (page 4-11).
2. Open the Rear Door.
3. Use the Up and Down Arrow buttons to select Printer > IOT Diag > DI-5.
4. Operate the actuator to check sensor function.
5. Confirm the number shown on the display increases every time the actuator is
operated.
6. Press the Stop button to stop the test.
7. Close the Rear Door.
s6000-144
Registration Sensor
Actuator
To Next Page
