Xerox PHASER 6010 Service Manual

4-48 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
Rear Cover Interlock
1. Enter Service Diagnostics (page 4-11).
2. Use the Up and Down Arrow buttons to select Printer > IOT Diag > Digital
Input > DI-7.
3. Open and close the Rear Door to actuate the switch.
4. Confirm the number shown on the display increases every time the actuator is
operated.
5. Press the Stop button to stop the test.
6. Close the Rear Door.
s6015-076

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
