Propeller selection
0
1
2
3
4
5
6
7
8
9
10
A
Propeller selection
The size and type of propeller that is used will affect the performance of a boat and outboard motor
critically. Propellers greatly affect boat speed, acceleration, engine life, fuel economy, and even
boating and steering capabilities. An incorrect choice could adversely affect performance and could
also damage the engine seriously.
Use the following information as a guide for selecting a propeller that meets the operating conditions
of the boat and outboard motor.
Propeller size
The size of the propeller is indicated on the propeller boss end, and on the side of the propeller
boss.
a. Propeller diameter (in inches)
b. Propeller pitch (in inches)
c. Propeller type (propeller mark)
Selection
With the engine speed at full throttle operating range and under a maximum boat load, the engine
speed should be within the upper half of the full throttle operating speed range.
Regular rotation model
abc
a
b
c
Full throttle operating range
(F150A, FL150A): 5000–6000 r/min
Full throttle operating range
(F150B, FL150B): 4500–5500 r/min
Blade Dia. (in) Pitch (in) Mark Material Part number Remarks
3 15 1/4 15 M Aluminum 6G5-45941-01
3 14 5/8 16 M Aluminum 6G5-45952-00
3 14 1/2 17 M Aluminum 6G5-45947-01
3 14 19 M Aluminum 6G5-45945-01
3 13 3/4 21 M Aluminum 6G5-45943-01
3 13 1/2 23 M Aluminum 6G5-45949-00
3 15 3/4 13 M Stainless steel 6G5-45932-00
3 15 1/4 15 M Stainless steel 6G5-45970-02
3 13 3/4 17 M2 Stainless steel 6G5-45978-03
3 13 3/4 19 M2 Stainless steel 6G5-45974-03
3 13 3/4 21 M Stainless steel 6G5-45972-02
3 13 3/8 23 M Stainless steel 6G5-45976-01
