Yamaha F150A - Connecting the Communication Cable

4-5
YDIS
0
1
2
3
4
5
6
7
8
9
10
A
Connecting the communication cable
CAN-Line
1. CAN-Line harness
2. Adapter cap
3. Adapter
4. USB cable
5. Hub
K-Line
1. Adapter
2. Adapter cap
3. USB cable
4. K-Line harness
a. YDIS coupler (gray)
3. Adapter
4. USB cable
5. Hub5. Hub
2. Adapter cap
1. CAN-Line harness
4. K-Line harness
1. Adapter
3. USB cable
2. Adapter cap
a. YDIS coupler
