Yamaha F150A - Clamp Bracket and Swivel Bracket

9-28
Clamp bracket and swivel bracket
0
1
2
3
4
5
6
7
8
9
10
A
No. Part name Q’ty Remarks
18 Washer 2
19 Nut 2
20 Anode 1
21 Plate 2
22 Bolt 4 M6 × 30 mm
23 Ground lead 1
24 Bushing 2
25 Collar 1
26 Pin 2
27 Distance collar 2
28 Pin 1
29 Spring 1
30 Hook 1
31 Bolt 1 M6 × 10 mm
32 Screw 1 M5 × 35 mm
33 Trim sensor cam 1
34 Clamp 1
1
2
3
3
3
3
3
3
4
5
6
8
7
8
9
10
10
11
11
12
13
14
15
16
17
18
19
20
21
21
22
22
23
24
25
26
27
27
28
26
26
26
2727 28
29
30
31
32
33
34
35
36
3 N·m (0.3 kgf·m, 2.2 ft·lb)
15 N·m (1.5 kgf·m, 11.1 ft·lb)
4 N·m (0.4 kgf·m, 3.0 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
