Yamaha F150A - Removing the Steering Arm; Installing the Steering Arm

9-25
Steering arm
Removing the steering arm
1. Remove the circlip “1”, and then remove
the steering yoke “2” by striking it using a
copper hammer.
2. Remove the washer “1”, bushing “2”,
O-ring “3”, and bushing “4”.
3. Remove the steering arm from the swivel
bracket.
Installing the steering arm
1. Install the washer “1” and bushing “2”
onto the steering arm “3”, and then install
the steering arm “3”.
2. Install the bushing “1”, a new O-ring “2”,
the bushing “3”, and the washer “4”.
3. Install the steering yoke “1” so that it
faces the same direction as the steering
arm “2” (aligning “a” with “b”).
1
1
2
4
3
2
1
1
2
3
1
2
3
4
