Yamaha F150A - Lower Unit

8-45
Lower unit (counter rotation model, L-transom model)
Lower unit (counter rotation model, L-transom model)
No. Part name Q’ty Remarks
1 Hose nipple 1
2 O-ring 1 Not reusable
3 Check screw 1
4 Gasket 2 Not reusable
5Dowel 2
6Grommet 1
7 Bolt 1 M10 × 45 mm
8 Lower unit 1
9Spacer 1
10 Propeller 1
11 Spacer 1 Except SDS propeller
12 Washer 1
13 Cotter pin 1 Not reusable
14 Propeller nut 1
15 Spacer 1 SDS propeller
16 Damper 1 SDS propeller
17 Trim tab 1
12
11
13
14
55 N·m (5.5 kgf·m, 40.6 ft·lb)
17
9
8
10
5
5
3
4
20
20
7
6
19
4
18
2
1
15
16
43 N·m (4.3 kgf·m, 31.7 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
