Yamaha F150A - Water Pump and Shift Rod (Counter Rotation Model)

8-51
Water pump and shift rod (counter rotation model)
Water pump and shift rod (counter rotation model)
No. Part name Q’ty Remarks
1 Shift rod 1
2 E-clip 1
3 O-ring 1 Not reusable
4Plate 1
5Bolt 3 M6 × 20 mm
6 Oil seal 1 Not reusable
7 Collar 1
8Spacer 1
9 Washer 2
10 Wave washer 1
11 Impeller 1
12 Outer plate cartridge 1
13 Gasket 1 Not reusable
14 Woodruff key 1
15 Dowel 2
16 Plate 1
17 Rubber seal 1
2
15
14
15
3
4
5
5
6
5
7
8
9
10
9
11
22
22
22
12
13
16
17
21
24
23
20
19
18
1
