4-3
YDIS
0
1
2
3
4
5
6
7
8
9
10
A
1. Start
2. Engine
3. Diagnosis
4. Diagnosis
5. Diagnosis Record
6. Engine Record
7. Engine operating hours by RPM
8. Engine Monitor
9. Digital Display
10. Graph Display
11. Input Setting
12. Component Test
13. Stationary Test
14. Active Test
15. Data Logger
16. Logger Graph
17. ECM Rec Graph
18. Logging
19. Record Set
20. Show Data
21. Clear Data
22. Boat System
23. Tilt Limiter
24. R/C System Reset
25. Maintenance
26. Engine oil change record
27. Update
28. Setting
29. Off Line
30. CAN Information
31. Communication List
32. Bus Statistics
4. Diagnosis
Displays diagnosis codes recorded in the engine ECM, item names, and current item conditions.
This enables detection of items with problems. The trouble codes displayed are the same as those
described in this chapter. See “Trouble code and checking step” (4-8).
5. Diagnosis Record
Displays diagnosis codes recorded in the engine ECM, item names, and when problems are
detected. The fault diagnosis history can be erased. The trouble codes displayed are the same as
those described in this chapter. See “Trouble code and checking step” (4-8).
7. Engine operating hours by RPM
Displays both operating hours and total operating hours for different engine speeds.
8. Engine Monitor
Displays engine ECM conditions (sensor information) in real time. “9. Digital Display” displays
these in digital form, and “10. Graph Display” displays these in graph form. Additionally, connect-
ing a commercially available external device and configuring “11. Input Setting” enables display of
the Engine Monitor.
13. Stationary Test
When the engine is stopped and the shift is in the N position, operate the parts to check, and per-
form tests to check operating conditions and operating noise.
Engine speed Throttle valve opening Engine shut-off switch
Intake air pressure ISC valve opening Shift position switch
Atmospheric pressure Fuel injection duration Multi-engine system
Ignition timing Intake air temperature Engine start switch
Battery voltage Engine temperature
Thermoswitch
TPS voltage Oil pressure Shift cut-off switch
Activate ignition coil #1 & #4 Activate injector (#1–#4) Activate ISC valve
Activate ignition coil #2 & #3 Activate electric fuel pump
