7-32
Wiring harness
7. Install the joint connectors “a”.
8. Install the 10-pin wiring harness coupler
“b” to the holder “1”.
9. Connect the engine temperature sensor
coupler “a”.
10. Install the ground leads “1”.
11. Connect the oil pressure sensor coupler
“a”.
12. Install the bracket “1”.
13. Connect the thermoswitch connectors
“a”.
1
b
a
1
a
a
1
1
a
To Next Page
