8-31
Drive shaft and lower case (regular rotation model)
7. Install the trim tab and propeller. See
steps 6–9 in “Installing the lower unit (L-
transom model)” (8-29).
8. Fill the lower unit with gear oil up to the
proper level. See steps 5–9 in “Changing
the gear oil” (10-11).
Lower case mounting bolts “10” and “11”:
48 N·m (4.8 kgf·m, 35.4 ft·lb)
10
11
3
4
6
1
9
8
7
7
8
5
5
10
1
2
2
5
5
