Yamaha F150A - Page 356

8-49
Lower unit (counter rotation model, X-transom model)
No. Part name Q’ty Remarks
18 Washer 1
19 Cotter pin 1 Not reusable
20 Propeller nut 1
21 Spacer 1 SDS propeller
22 Damper 1 SDS propeller
23 Trim tab 1
24 Bolt 1 M10 × 200 mm
25 Drain screw 1
16
23
15
14
18
17
19
20
7
7
3
4
5
5
13
12
7
10
11
8
9
9
8
5
5
7
25
4
24
6
1
2
2
1
21
22
43 N·m (4.3 kgf·m, 31.7 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
48 N·m (4.8 kgf·m, 35.4 ft·lb)
55 N·m (5.5 kgf·m, 40.6 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
