Drive shaft and lower case (counter rotation model)
No. Part name Q’ty Remarks
18 Reverse gear 1
19 Water inlet cover (PORT) 1
20 Screw 1 M5 × 45 mm
21 Needle bearing 1 Not reusable
22 Pinion 1
23 Pinion nut 1
14
16
15
9
10
19
20
1 N·m (0.1 kgf·m, 0.7 ft·lb)
8
7
6
5
4
3
2
1
6
12
11
13
18
21
22
23
17
17
95 N·m (9.5 kgf·m, 70.1 ft·lb)
To Next Page
