Yamaha F150A - Page 429

9-42
PTT cylinder
0
1
2
3
4
5
6
7
8
9
10
A
No. Part name Q’ty Remarks
18 Dust seal 2 Not reusable
19 Circlip 2
20 Free piston 1
21 O-ring 1 Not reusable
65 N·m (6.5 kgf·m, 47.9 ft·lb)
2
5
11
10
8
12
20
21
19
18
17
16
14
15
13
1
9
8
8
7
6
8
4
3
7 N·m (0.7 kgf·m, 5.2 ft·lb)
160 N·m (16.0 kgf·m, 118.0 ft·lb)
19
18
17
16
14
15
13
160 N·m (16.0 kgf·m, 118.0 ft·lb)
150 N·m (15.0 kgf·m, 110.6 ft·lb)
