Accutome A-Scan Plus User’s Guide
Symbol
Definitions for
the Accutome
Statements, graphics and symbols listed below are used
on components of the Accutome A-Scan Plus.
Descriptions and meanings are listed to the right of the
symbols.
"Attention! Consult instruction manual."
Single phase alternating current
When pressed turns the power on and off.
Serial Link connector
Printer connector
Keyboard connector
Foot switch input connector
