266
Accutome A-Scan Plus User’s Guide
Storage/Range
Specifications
Table 10 below lists the data storage and range
specifications of the Accutome A-Scan Plus .
Table 10 Data Specifications
Stored Data Capacity
Waveforms / Patient 10
Stored Patients 100
IOLs 45 total; 15 groups of 3
Post Operative Results 1000 total; 50 per IOL
Waveform Data
Data Points Per Waveform 4096
Max Depth At 1555 m/sec 64 mm
Gain Adjustment Range 20 dB
Eye Type Storage
Factory Eye Types 7
User Eye Types 2
Custom Eye Types Unlimited
Factory Aqueous/Vitreous Materials 3
User Aqueous/Vitreous Materials 2
Factory Lens Materials 4
User Lens Materials 2
Material Velocity Range 500 to 9999 m/sec
Assumed Lens Thickness Range 0 to 9.99 mm
K Readings Range 20 to 60 D
5 to 19.99 mm
