Specifications
Overview This section provides the physical and operational
specifications of the Accutome A-Scan Plus.
Physical
Specifications
Table 5 below lists the physical specifications of the
instrument and associated peripherals.
Table 5 Accutome A-Scan Plus Physical Specifications
Main Unit
Dimensions 30.2 X 19.05 x 4.83 cm (11.9” x 7.5” x 1.9”)
Weight 1.98 Kg (4 lbs, 6 oz).
DC Input 12 V, 1.25 A
Display
Type Monochrome Liquid Crystal Display (LCD)
Size 18.29 cm (7.2”) diagonal viewable area
Resolution 640 x 480 pixels, 16-shades of gray
External I/O Connectors
Printer IEEE-1284 type C
Serial RS-232C, DCE, 9-pin D-Sub, female
Keyboard PS/2, 6-pin mini-DIN, female
Foot Switch 3.5 mm mono phone jack
DC Power 2.5 mm DC coaxial
