Accutome A-Scan Plus User’s Guide
Connecting the Keyboard
To connect the keyboard:
1. Locate the keyboard connector, on the side, at the
left of the instrument (see Figure 6 on page 22).
2. The keyboard cable is keyed with a side that is flat.
3. Insert the connector of the keyboard cable, with
the flat side of the connector pointing to the back of
the instrument, into the keyboard connector.
WARNING! CONNECT THE
KEYBOARD ONLY
WHEN THE Accutome
A-Scan Plus IS
TURNED OFF.
DAMAGE TO THE
INSTRUMENT MAY
RESULT IF THE
POWER IS ON.
