56
Accutome A-Scan Plus User’s Guide
you press the knob again it will save the changes to the
field and deactivate it.
If you are in a soft menu, requiring a user response, and
you turn the data knob or press another ignored button
the active soft menu will flash and beep.
Screens The Accutome A-Scan Plus is set up as a series of high
level screens with logically linked lower level screens.
Each of the high level screens is accessed by pressing
one of the dedicated function buttons. Two of the
dedicated function buttons, Calculate and Preferences
allow you to scroll through the lower level screens
through the dedicated button. It is in the various screens
that you perform all operations; measuring patients,
calculating lens replacements, setting up the Accutome
A-Scan Plus, setting up IOL groups, personalizing lens
constants, etc. The name of each screen is displayed in
the top right corner.
What the Screen Displays
Each screen displays tips for the active area, soft menus
at the bottom of the screen and tables of information
related to the screens function. For example, the
Calculate Screen displays the Patient name and ID, the
IOLs for the selected IOL Group, the calculation formulas
and the K1, K2 and Target values.
Types of Information
The information displayed on each screen is determined
by the screen’s function. For example, the Patient
Records Screen displays all saved patient records.
Screen items that have a white background may be
selected and modified using the knob.
Any item on a screen followed by an asterisk * indicates
that the value has been changed and that it is non-
standard, or, custom.
Any menu item followed by an ellipsis .... will take you to
another screen when you push button beneath the menu
item.
