Accutome A-Scan Plus User’s Guide
How Buttons,
Screens and
Knob Work
Together
The buttons, screens and knob work together in the
following manner:
1. Select a high level screen by pressing one of the
dedicated function buttons.
2. In the selected screen rotate the knob to select a
field requiring change.
3. Press the knob, or the Affirmative button to acti-
vate the field.
4. Make the appropriate changes to the field either by
selecting a pre-entered value or entering the
required information.
5. Press the knob, or the Affirmative button to save
the changes made to the field.
6. Rotate the knob to select the next field requiring
change.
Changing Fields and Table Cells
When you are in any screen every field that is in a white
box can be changed. Anything not in a white box can not
be changed.
When you are moving around in tables, such as the IOL
Group table, and you are making changes to a selected
cell, press once and the cell becomes active. Pressing
the same cell twice escapes the table.
Active Area
The active area on any screen is surrounded by a
dashed border.
Text Entry
Certain screens require text entry. The Accutome A-
Scan Plus has an optional keyboard, but if you don’t
have the keyboard the Accutome A-Scan Plus will
automatically provide you with a new soft menu of
alphanumeric characters. You select the various
characters by rotating the knob and enter the characters
into the text field by pressing on the knob or the
Affirmative button. When you have completed the text
entry you can return to the screens by pressing the
button beneath the selection "Done".
